How to undervolt a GPU for mining?

Undervolting GPUs in mining rigs can significantly cut power consumption and heat output, improving efficiency and hardware longevity without sacrificing much performance.

Jul 13, 2025 at 11:08 pm

Understanding GPU Undervolting for Mining

Undervolting refers to the process of reducing the voltage supplied to a GPU (Graphics Processing Unit) while maintaining or slightly adjusting its clock speed. In the context of cryptocurrency mining, this technique is widely used to lower power consumption and reduce heat output, which directly impacts profitability and hardware longevity.

When mining cryptocurrencies such as Ethereum, Ravencoin, or Ergo, GPUs run at full capacity for extended periods. This constant workload generates significant heat and consumes large amounts of electricity. By undervolting, miners aim to achieve an optimal balance between hash rate performance and energy efficiency without sacrificing too much in terms of computational output.

Why Miners Use Undervolting Techniques

The primary reason miners undervolt their GPUs is to minimize power usage. Electricity costs are one of the largest operational expenses in mining. A reduction in voltage can lead to noticeable savings on power bills, especially when running multiple GPUs over long durations.

Another critical benefit is thermal management. Lower voltages result in reduced heat generation, which helps maintain stable operating temperatures and extends the lifespan of the GPU. Cooler components also tend to perform more consistently and may allow for better overclocking headroom if needed.

Additionally, undervolting can help stabilize mining rigs that suffer from crashes or instability due to power delivery issues. Many modern GPUs have built-in flexibility that allows users to tweak these settings safely through software tools.

Tools Required for Undervolting a GPU

Before starting the undervolting process, you'll need specific software depending on your GPU manufacturer:

• For NVIDIA GPUs, use MSI Afterburner in combination with Precision X1.
• For AMD GPUs, Radeon Software Adrenalin Edition provides native tuning options, although third-party tools like Trixx (for Sapphire cards) or WattMan (built into AMD drivers) are commonly used.

Ensure all software is up-to-date and compatible with your operating system. It’s also recommended to have a monitoring tool such as HWInfo64 or GPU-Z installed to track real-time metrics like voltage, temperature, clock speeds, and power draw during testing.

Step-by-Step Guide to Undervolting Your GPU

To begin undervolting your GPU for mining, follow these steps carefully:

• Open MSI Afterburner (or the appropriate tool for your GPU brand).
• Ensure your mining software is running to simulate real-world load conditions.
• Start by reducing the core voltage offset in small increments—typically 50 mV at a time.
• Monitor the hash rate closely after each adjustment to detect any performance drops.
• If the GPU remains stable and maintains acceptable hashrate levels, continue lowering the voltage further.
• Pay attention to error messages or screen artifacts, which indicate instability.
• Once signs of instability appear, increase the voltage slightly until stability returns.
• Save the final profile so it loads automatically on system startup.

For NVIDIA cards using MSI Afterburner, adjust the Voltage (mV) slider under the Tuning tab. For AMD cards using WattMan, navigate to the Voltage/Frequency curve editor and lower the voltage points across relevant clock frequencies.

Testing Stability and Performance Post-Undervolting

After applying undervolt settings, it's crucial to stress test the GPU under mining workloads to ensure reliability. Run your mining software continuously for several hours while monitoring:

• Hash rate
• Temperature
• Power consumption
• Error logs

If the card performs stably without errors or significant drops in hashrate, your undervolt settings are likely safe. However, if the GPU starts crashing or showing visual glitches, you’ve pushed the voltage too low. In that case, gradually increase the voltage until the system stabilizes again.

Some mining platforms, such as NiceHash or PhoenixMiner, include built-in crash detection features that can help identify unstable configurations. You can also use MemTestGpu or OC Scanner Lite for additional diagnostics.

Potential Risks and Considerations

While undervolting is generally safe, there are some risks to be aware of:

• Stability issues can arise if voltage is reduced too aggressively.
• Some older or poorly manufactured GPUs might not respond well to voltage adjustments.
• Improper undervolting can lead to unexpected shutdowns or data corruption during mining.
• Always back up original BIOS settings before making major changes in case you need to revert.

It's important to note that undervolting does not void warranties unless physical modifications are made to the card. Most adjustments are done purely through software and can be reverted easily.

Frequently Asked Questions (FAQ)

Q: Can undervolting damage my GPU?

A: No, undervolting itself does not damage a GPU. In fact, it often reduces stress on components by lowering power consumption and heat output. However, extreme undervolting beyond safe thresholds may cause instability or crashes.

Q: Does undervolting affect hashrate significantly?

A: Minor undervolting usually results in negligible hashrate loss. With proper tuning, many miners achieve up to 20% power savings with only a 1–5% drop in hashrate.

Q: Is undervolting possible on all GPU models?

A: Most modern NVIDIA and AMD GPUs support undervolting through software tools. However, some locked-down models, especially certain OEM versions, may restrict access to voltage controls.

Q: Should I undervolt every GPU in a multi-GPU rig individually?

A: Yes, each GPU may behave differently due to manufacturing variances. It's best to tune each card separately to ensure optimal performance and stability across the entire mining rig.
